How to adjust the size of the automatic wire printer?

How to adjust the size of the automatic wire printer?

The operator of the fully automatic wire printer often troubles in order to regulate the size of the fully automatic wire printer. In fact, the adjustment of the fully automatic wire printer is similar to other wire printers. The size of the machine.

The size adjustment of the automatic wire printer:

1. Adjustment of the parallelism of the three -layer between the guide rail, printing version, and working platform

If these three layers are not parallel, the network printer is almost impossible to work. Generally, a guide or platform is used as the benchmark.

2. Adjust the platform and guide rail

The platform and the guide rail should be parallel. The ink scraping version is moved along the rail. If the two are not parallel, the scraper will not always contact the platform with a certain pressure, and even the gap. This adjustment has been adjusted before the machine is out of the factory. Fully automatic silk net printing machine

3. The adjustment of the screen version and the platform

The screen printing version should be parallel to the platform, otherwise the network distance is inconsistent, causing the scraper printing pressure and the deformation of the screen printing. Therefore, the flatness of the net frame itself should be guaranteed. Require.

4. Adjustment of mesh distance

The network version and the product must have a distance of 2-5 mm. This is called the network distance.

5. Scratch of fully automatic wire printer

The knife mouth of the scraper with silk printed must be sharp. After a long time, there is no right angle, and it becomes a rounded corner. The printed things are very vague and the lines are thick.
