Automatic Flute Laminator production method, safety operating procedures, and characteristics

The production method of the adjustment device of Automatic Flute Laminator: The adjustment device of the existing Automatic Flute Laminator. Its adjustment device is generally divided into two parts and short shaft parts. The long axis part is a long axis that is adjusted, one with the gear; the short shaft is a short shaft material made of chromium stick, one with a gear and the other end with a hand wheel. The gears of the long shaft and the short shaft part are messed together. With the development of the packaging industry after the Indian, the requirements for the coordination of automatic Flute Laminator's noodle paper and corrugated paper are more accurate. In terms of noodle paper and corrugated paper, two paper is required. It is inevitable that the above -mentioned conventional adjustment devices must also be designed more accurately. The conventional adjustment device is to shake the short shaft hand wheel and touch the gear during the operation of the mechanical regulation. Make the push noodle paper and corrugated paper. In this conventional adjustment device, it is more accurate for some small noodle paper and corrugated paper with small specifications. In the case of large -scale noodle paper and corrugated paper, it is not accurate, and waste paper is prone to occur, which brings inconvenience to the debugger. Full automatic paper mounting machine safety operation procedure: boot for a few minutes, check whether the motion of the machine has different sounds and other phenomena.

The characteristic of Automatic Flute Laminator: 1. The exquisite gritter design makes the adjustment of paper bite and paper bite time in a small space, and the transmission of paper is more accurate and stable. 2. The unique glue method enables the amount of glue to achieve continuous linear adjustment, and controls the amount of glue more accurately. The amount of glue per square meter is about 10 grams. 3. The innovative pressure regulating mechanism has changed the complicated adjustment method in the past, making the machine control easier and faster. 4. According to customer needs, draw on the concept of continuous paper transmission of rubber printers, and develop two positioning paper delivery mechanisms. The operator only needs to give the paper to the preliminary position. Demand reduces work intensity. Automatic Flute Laminator Features: High positioning accuracy, bottom paper ** ahead.

Automatic Flute Laminator Safety Operation Regulations: 1. Before turning on, add an appropriate amount of lubricant to the part that needs lubrication. 2. Carefully check the fasteners, such as screws, whether the parts such as the hand are loose or shed. 3. Whether each roller and belt are tip and other debris. 4. Turn on the test for a few minutes, check whether the motion of the machine has different sounds and other phenomena. Check the urgent stops, and the control button is sensitive and effective. 5. Each operating handle, switch button, adjustment device, and whether the safety device is in normal shutdown position. 6. During the operation of the machine, check the operation of each motor, reducer, fan, and control the operation of the electrical box. If there is no noise, abnormal phenomena such as leakage, and other abnormal phenomena are immediately shut down for maintenance.

Water -based automatic flute laminator Note: 1. Cleaning problem: Due to the fast drying of water -based environmentally friendly glue, if there is no flow of static, it will dry into a solid block. If it is attached to the adhesive roller or pressure roller, it will cause too much local pressure when the local adhesive coating is too small. Therefore, in the process of mounting paper, keep the glue roller and the pressure roller clean. If there are too many dust in the surrounding environment of the paper machine, snowflakes will appear in the printed matter, so you should pay attention to environmental hygiene. The glue should not be used back to the glue barrel to seal it, or the method of filtering before the glue is used. 2. Printing powder: Water -based glue itself is also limited by dissolving. If the printed spraying powder is too large, the excess part cannot be completely dissolved by the glue, and a large area of snowflakes will appear. To solve this problem, you can minimize the amount of powder spraying as much as possible by coordinating the upper and lower processes. At the same time, appropriately increase the amount of glue, increase the ability of glue to dissolve powder, and clean the surface of the printed surface before mounting. Features of automatic paper mounting machine: It is suitable for the mounting of 175G-500G color printing paper with A/B/C/D/E/F corrugated paper.

Automatic Flute Laminator to maintain a high -precision method: After the mold cutting version is installed, CTF is taken, and a prepared cardboard (hereinafter referred to as "pressure -regulating cardboard") is taken to make the right paper side of the cardboard and the side platform and the lower platform The right edge is flat, and then paste the pressure -regulating cardboard on the lower platform with a tape. Adjust the pressure according to the experience, the development history of the motivation machine, and press the knife marks on the cardboard. At this time, the accuracy of the mold cutting pressure is not high. As long as it is controlled to cut off the pressure regulating cardboard, and at the same time, you can see the knife marks. Then you can adjust the mold cutting pressure based on the knife marks. Take the pressure -tone cardboard out of the lower platform, and draw the color from the machine from the machine, and then paste the pressure regulating cardboard with a tape on the upper steel plate. Because the pressure -regulating cardboard is placed with the right edge and front edge of the lower platform when the stunning cardboard is placed, the right edge and front edge of the right edge and front of the frame are fixed. It should be used for long -term use with a stroke on the frame steel plate. It can be convenient for the signal position of the pressure -regulating cardboard to draw on the steel plate, and then fix it with a tape. Automatic Flute Laminator Simple Debugging method: Paper paper placed in the center of the paper mounting machine.

Automatic Flute Laminator Features: Full automatic glue supplement system.

Precautions for the use of water -based papermaking machine: 1. Printing powder: Water -based glue itself is also limited by dissolving. If the printer spray is too large, the extra part cannot be completely dissolved by glue, and a large area of snowflakes will appear. To solve this problem, you can minimize the amount of powder spraying as much as possible by coordinating the upper and lower processes. At the same time, appropriately increase the amount of glue, increase the ability of glue to dissolve powder, and clean the surface of the printed surface before mounting. 2. Prints Discolor: It mainly appears in large -scale gold and cashmere products. This is due to the chemical reactions that have active chemical properties in glue. If this problem is encountered, we can use special gold or special glue for printing products, or percourse first and coating, and the effect is also very good.
